Schneider Electric MG24150 Multi 9 - C60 UL1077 - MCB - 3P - 25 A - B Curve - 480Y/277 V - 5 kA

Product Description

Schneider Electric MG24150 is a thermal magnetic supplementary protector designed for circuit protection. This device features a three-pole design and operates at a current of twenty-five amps with a voltage rating of four hundred eighty volts star and two hundred seventy-seven volts. It is suitable for various electrical distribution applications.

• Three-pole configuration
• Thermal magnetic protection type
• Meets multiple safety standards including CSA and UL

Product Highlights

Ideal for industrial and commercial electrical systems where reliable circuit protection is necessary.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Catalog Number: MG24150
• Weight: 0.73 lb
• Depth: 2.87 Inches
• Width: 2.13 Inches
• Height: 3.19 Inches
• Voltage: 240 Volt
• Amperage: 25 Amp
• Number of Poles: 3 Pole
• Country of Origin: France
• Operating Temperature: -30 to 70 Degrees C
• Certifications: CCC, CSA, IEC, UR
• Warranty Length: 18 months
