Schneider Electric M9L22480 surge arrester, Mu

Product Description

Schneider Electric's M9L22480 is a surge arrester designed for critical electrical installations. This surge arrester can be used in service entrance, branch panels, and control panel environments, ensuring protection against electrical surges. It is classified as type 1, making it suitable for various applications in the electrical distribution network.

• Maximum discharge current of seventy-five kA
• Compatible with thirty A and C curve tripping circuit breakers
• Can be mounted on DIN rail for easy installation

Product Highlights

This product effectively safeguards electrical systems from transient overvoltages. It has an impressive maximum continuous operating voltage of two hundred seventy-five VAC.

Product Information

Standard Information

• Catalog Number: M9L22480
• Brand: Schneider Electric

Technical Specifications

• Height: Ninety-one point seven mm
• Width: Thirty-five mm
• Depth: Seventy-one point four mm
• Operating Temperature: Negative twenty-five to sixty degrees Celsius
• Storage Temperature: Negative forty to eighty-five degrees Celsius
• Weight: Three hundred forty grams
• Compliance Standard: UL 1449
