Schneider Electric M9L11120 surge arrester, Mu (Each)

Product Description

Schneider Electric M9L11120 is a surge arrester designed for various electrical installations including service entrances, branch panels, and control panel environments. This surge arrester connects directly to the electrical distribution network and has a surge arrester type classification of Type 1.

• Maximum discharge current of seventy-five kA
• Compatible with a thirty A C-curve tripping circuit breaker
• UC maximum continuous operating voltage of one hundred seventy-five VAC

Product Highlights

This product offers reliable protection against voltage spikes. It ensures that sensitive electronic equipment is safeguarded from damage caused by power surges.

Product Information

Standard Information

• Catalog Number: M9L11120
• Manufacturer: Schneider Electric

Technical Specifications

• Type: Surge Arrester
• Width: Two pitches of nine mm
• Degree of Protection: NEMA 1
• Operating Temperature: -25 degrees C to 60 degrees C
• Storage Temperature: -40 degrees C to 85 degrees C
• Complies with Standard: UL 1449
• Nominal Discharge Current: Twenty kA
• Maximum Voltage Protection Level: Six hundred V
