Schneider Electric M9F53110 Miniature Circuit Breaker 10A D Curve

Product Description

Schneider Electric offers the M9F53110 Miniature Circuit Breaker. This low voltage circuit breaker is designed for electrical protection. It is a single pole device with a rated current of ten amps and a D tripping curve. It provides short circuit protection with a breaking capacity of three kA at four hundred fifteen VAC. This product complies with industrial standards EN/IEC 60898-1 and EN/IEC 60947-2 for residential use.

• 1 pole with rated current of 10A
• Electrical endurance of up to 10,000 cycles
• Clips onto standard DIN rail for easy installation

Product Highlights

This circuit breaker offers safety by protecting against short circuits, earth leaks, and overloads. It is suitable for OEMs and control panel builders. The device operates at a voltage of two hundred forty VAC and has a rated insulation voltage of five hundred VAC.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: M9F53110

Technical Specifications

• Catalog Number: M9F53110
• Type: Miniature circuit breaker
• Number of Poles: 1 Pole
• Amperage: 10 Amp
• Width: 18 mm
• Height: 127 mm
• Depth: 72 mm
• Operating Temperature: -30°C to 70°C
• Storage Temperature: -40°C to 80°C
• Protection Degree: IP20
• Trip Type: Thermal-magnetic
