Schneider Electric M9F43220 Miniature Circuit Breaker 20A 2P D Curve 10kA

Product Description

Schneider Electric M9F43220 is a low voltage miniature circuit breaker (MCB). This unit features two protected poles with a rated current of twenty amps. The D tripping curve ensures reliable operation. It has a short circuit breaking capacity of ten kiloamperes at four hundred fifteen volts and adheres to EN/IEC 60947-2 standards. This circuit breaker is suitable for both industrial and residential applications, conforming to EN/IEC 60898-1 standards. It helps protect against short circuits, earth leakage, and overloads, making it ideal for original equipment manufacturers and control panel builders.

• Rated current: 20A
• Short circuit capacity: 10kA at 415VAC
• DIN rail mountable

Product Highlights

This circuit breaker is designed for durability and can withstand up to ten thousand electrical cycles and twenty thousand mechanical cycles. It operates at a voltage of two hundred forty volts, with an insulation voltage rating of five hundred volts. The product is suitable for mounting on a DIN rail with a width of four pitches of nine millimeters. It meets pollution degree 3 requirements and has an IP20 rating according to IEC/EN 60529 standards. Its operational temperature ranges from negative thirty degrees Celsius to seventy degrees Celsius, with a storage temperature from negative forty degrees Celsius to eighty degrees Celsius.

Product Information

Standard Information

• Catalog Number: M9F43220
• Manufacturer: Schneider Electric

Technical Specifications

• Brand: Schneider Electric
• Color: Gray
• Depth: 72 mm
• Height: 103 mm
• Width: 36 mm
• Voltage: 240 V
• Actuator: Toggle
• Amperage: 20 A
