Schneider Electric M9F43210 Miniature Circuit Breaker 10A 2P D Curve

Product Description

The Schneider Electric M9F43210 is a miniature circuit breaker designed for low voltage applications. This circuit breaker features a two-pole configuration, with a rated current of ten amps and a D tripping curve. It has a rated short circuit breaking capacity of up to ten kiloamperes at four hundred fifteen volts, meeting both EN/IEC 60947-2 standards. This product is suitable for residential and industrial use, providing essential protection against electrical faults.

• Two poles with a rated current of ten amps
• Breaking capacity up to ten kiloamperes
• Designed for OEM and control panel applications

Product Highlights

Reliable protection for electrical systems to prevent overloads, short circuits, and earth leakage.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Catalog Number: M9F43210
• Product ID: 1281082
• Country of Origin: United States

Technical Specifications

• Width: 36 mm
• Height: 103 mm
• Depth: 72 mm
• Voltage: 240 Volt
• Amperage: 10 Amp
• Number of Poles: 2 Pole
• Trip Type: Thermal-magnetic
• Operating Temperature: -30 to 70 degrees C
