Schneider Electric M9F43104 Miniature Circuit Breaker 1P 4A D Curve 14kA

Product Description

The Schneider Electric M9F43104 is a low voltage miniature circuit breaker (MCB) designed for effective electrical protection. This 1P circuit breaker has a rating of 4A and features a D tripping curve for reliable operation. It can handle short circuit breaking capacity up to 3kA at 415VAC, meeting both industrial and residential standards. This product integrates safety features to protect individuals and equipment from electrical faults.

• 1P configuration with 4A rated current
• Electrical endurance up to 10000 cycles
• Mountable on DIN rail

Product Highlights

The M9F43104 breaker is tailored for OEMs and control panel builders, ensuring robust protection against overloads, earth leakage, and short circuits. The operational voltage is 240VAC, with an insulation voltage of 500VAC and impulse withstand voltage of 6kV.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Model: M9F43104
• Width: 18 mm
• Height: 103 mm
• Depth: 72 mm
• Voltage Rating: 240 Volt
• Amperage Rating: 4 Amp
• Insulation Voltage: 500 VAC
• Impulse Withstand Voltage: 6 kV
• Trip Type: Thermal-magnetic
• Application: Distribution
• Operating Temperature: -30 to 70 Degrees Celcius
• Storage Temperature: -40 to 80 Degrees Celcius
• Country of Origin: France
• RoHS Compliance: Yes
