Schneider Electric M9F22302 Miniature Circuit Breaker (MCB) 2A C Curve 10kA

Product Description

Schneider Electric M9F22302 is a low voltage miniature circuit breaker (MCB) designed for protection in electrical applications. This three-pole breaker has a rated current of two amps and utilizes a C tripping curve. It provides short circuit breaking capacity of up to ten kiloamperes at four hundred fifteen volts, complying with EN/IEC 60947-2 standards.

• Rated breaking capacity up to 10kA at 415VAC
• Electrical endurance of 10,000 cycles
• Mechanical endurance of 20,000 cycles

Product Highlights

This circuit breaker works to protect both equipment and personnel from electrical faults, including short circuits, earth leakage, and overload conditions. It is ideal for use in applications by original equipment manufacturers (OEMs) and control panel builders.

Product Information

Standard Information

• Catalog Number: M9F22302
• Manufacturer: Schneider Electric

Technical Specifications

• Type: Miniature circuit-breaker
• Number of Poles: 3
• Rated Current: 2 A
• Voltage: 240 Volt
• Width: 54 mm
• Height: 81 mm
• Depth: 72 mm
• Operating Temperature: -30C to 70C
• Storage Temperature: -40C to 80C
• Protection Degree: IP20
• Insulation Voltage: 500 VAC
