Schneider Electric LX1FH2402 TeSys F - contactor coil - 240V AC 40...400Hz

Product Description

The Schneider Electric LX1FH2402 is a TeSys F AC coil designed for use in 240V applications at frequencies from 40 to 400Hz. This product is suitable for TeSys F three-pole and four-pole contactors, including models LC1 F265 and LC1 F330. It operates efficiently within voltage limits of 0.85 to 1.1 Uc and can function in environments up to fifty-five degrees Celsius. The coil is engineered for high operational rates, achieving up to 2400 cycles per hour.

• Voltage: 240V AC
• Frequency: 40 to 400Hz
• High operational rate: up to 2400 cycles/hour

Product Highlights

This contactor coil is Green Premium compliant, adhering to RoHS and REACh standards, ensuring it meets environmental requirements.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Product ID: 1097452

Technical Specifications

• Catalog Number: LX1FH2402
• Coil Voltage: 240 V AC
• Frequency Range: 40 - 400 Hz
• Operating Temperature: -5 to 55 degrees Celsius
• Weight: 1.65 lb
• Net Weight: 0.75 kg
• Country of Origin: Czech Republic
• Warranty Length: 18 months
