Schneider Electric LRD4369 Square D 600 Volt 140 Amp 3-Pole Bi-Metallic Screw Clamp Terminal Thermal Overload Relay

Product Description

The Schneider Electric LRD4369 is a thermal overload relay designed for use with TeSys D contactors. It protects motors rated up to sixty-three kilowatts at four hundred volts with a thermal setting range from one hundred ten to one hundred forty amperes, tripping at class ten amperes with phase unbalance protection.

• Thermal protection for motors up to 63kW at 400V
• Manual test and reset buttons with automatic reset
• Multi-standards certified for global use

Product Highlights

This thermal overload relay features a compact design, direct mounting on TeSys D contactor terminals, and a built-in trip signaling mechanism.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square D / Schneider

Technical Specifications

• Model Number: LRD4369
• Voltage Rating: 1000 Volt
• Current Rating: 140 Amp
• Number of Poles: 3 Pole
• Width: 5.20 inches
• Depth: 132 mm
• Weight: 1.98 lb
• Operating Temperature: -20°C to 60°C
• Country of Origin: United States
• Warranty Length: 18 months
• Applications: LC1D150; Motor protection
