Schneider Electric LRD340 TeSys Deca, thermal overload relay, 30 to 40 A, class 10A, EVERLINK

Product Description

Schneider Electric LRD340 is a thermal overload relay designed to work with TeSys D contactors to form a motor starter. This relay caters to current ratings from 40 amps to 65 amps and offers an adjustable trip rating from 30 to 40 amperes, adhering to Class 10A standards. The LRD340 utilizes differential thermal technology to detect overcurrents in motors and will disconnect power to the motor to prevent damage to the windings.

• Adjustable trip current from 30 to 40 amps.
• Compatible with 40 to 65 amp TeSys D contactors.
• Uses EVERLINK terminals for reliable connections.

Product Highlights

This relay enhances motor protection and ensures equipment longevity by preventing overcurrent damage. Its manual or automatic reset feature provides flexibility in various applications.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D

Technical Specifications

• MPN: LRD340
• Type: Differential thermal overload relay
• Trip Type: Thermal - ambient compensated bi-metallic/differential class 10
• Voltage: 690 Volt
• Weight: 0.83 lb
• Country of Origin: France
• Standard: CSA C22.2 No 60947-4-1, UL 60947-4-1
• Operating Temperature: -20C to 60C without derating
• Number of Poles: 3 Pole
• Control Type: Red push-button stop; Blue push-button reset
