Schneider Electric LP4K0601BW3 Iec Contactor 3P 6A 24VDC

Product Description

The SCHNEIDER ELECTRIC LP4K0601BW3 is a 3-pole IEC contactor designed for non-reversible motor control and switching applications in industrial and commercial electrical systems. It operates on a 24 VDC coil voltage and is rated at 6 amps at 440 VAC. The unit includes a normally closed (NC) auxiliary contact configuration. Weighing 0.48 pounds and measuring 2.6 inches in height, 1.9 inches in width, and 2.5 inches in depth, it is a compact device suited for panel and enclosure mounting. Licensed electricians and controls technicians are the primary installers.

This contactor is used in light-duty motor starter circuits, control panels, and machinery switching applications where a low-voltage DC coil signal controls an AC load circuit. Its 24 VDC coil makes it compatible with PLC output cards and low-voltage control systems commonly found in automated equipment, HVAC control panels, and process machinery. The NC auxiliary contact provides feedback or interlocking capability in control logic circuits.

Key Features

• 3-pole configuration for three-phase or multi-phase switching
• 24 VDC coil voltage compatible with PLC and low-voltage control systems
• 6A rating at 440 VAC for light-duty motor and load control
• Normally closed (NC) auxiliary contact for interlocking or status feedback
• Non-reversible action for single-direction motor control applications
• Compact form factor at 2.6 x 1.9 x 2.5 inches for space-constrained panels
• RoHS compliant with UL Listed, CSA, IEC 60947, VDE 0660, and BS 5424 certifications

Compatibility

Designed as an OEM-style IEC contactor replacement for light-duty 3-pole non-reversible motor control circuits requiring a 24 VDC coil and NC auxiliary contact, in compliance with IEC 60947 standards.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the control panel before removing or installing the contactor. Verify coil voltage supply matches the 24 VDC rating before energizing. Confirm auxiliary contact wiring aligns with the NC configuration before commissioning the control circuit.
