Schneider Electric LP1K0610BD3 Iec Contactor 3P 6A 24VDC

Product Description

The SCHNEIDER ELECTRIC LP1K0610BD3 is a 3-pole IEC contactor with a 24 VDC coil, rated at 6 amps at 440 VAC. It includes a normally open (NO) auxiliary contact configuration and is built for reliable switching of three-phase and single-phase loads in industrial and commercial control panels. Licensed electricians and panel builders install this contactor in motor starters, lighting circuits, and load-switching applications. The compact form factor measures 2.6 inches in height, 2.4 inches in width, and 1.9 inches in length, making it well-suited for tight enclosure builds. At 0.49 pounds, it adds minimal weight to a panel assembly.

This contactor is used in residential, commercial, and light industrial control systems where a low-voltage DC coil signal is required to switch AC loads. Typical applications include motor control circuits, HVAC equipment contactor banks, pump starters, and automated panel assemblies. The 24 VDC coil voltage allows direct integration with standard PLC outputs and low-voltage control circuits. The NO auxiliary contact supports control circuit feedback, interlock wiring, and status indication in the broader control scheme.

Key Features

• 3-pole configuration for three-phase or multi-leg load switching
• 24 VDC coil voltage for direct compatibility with PLC and low-voltage control circuits
• 6A rating at 440 VAC for light motor and load switching duty
• Normally open (NO) auxiliary contact included for interlock and feedback wiring
• Compact footprint at 2.6 x 2.4 x 1.9 inches for space-constrained panel installations
• Meets multiple international standards including UL Listed, CSA, IEC 60947, RoHS Compliant, and VDE 0660

Compatibility

Designed as an OEM-style IEC contactor replacement for 3-pole, 24 VDC coil applications in industrial and commercial control panel assemblies conforming to IEC 60947 standards.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and any applicable local codes. De-energize and lock out the control panel before removing or installing the contactor. Verify coil voltage supply matches the 24 VDC rating before energizing the circuit. Confirm all load-side and control-side wiring connections are secure and torqued per panel terminal specifications before returning the system to service.
