Schneider Electric LP1K0601BD3 Iec Contactor 3P 6A 24VDC

Product Description

The SCHNEIDER ELECTRIC LP1K0601BD3 is a 3-pole IEC contactor rated at 6 amps at 440 VAC with a 24 VDC coil. It is a non-reversible contactor configured with a normally closed (NC) auxiliary contact. Contactors of this type control power circuits in motor starters, control panels, and automated equipment by opening and closing under the command of a low-voltage control signal. This unit is compact, measuring 1.9 inches in height, 2.6 inches in width, and 2.4 inches in depth, making it suitable for dense panel builds. Licensed electricians and industrial control panel builders are the primary installers.

The LP1K0601BD3 is suited for use in light-duty motor control, HVAC equipment control panels, and industrial automation enclosures where IEC-standard contactors are specified. Its 24 VDC coil makes it compatible with common low-voltage control circuits found in building automation and process control applications. The non-reversible configuration is appropriate for single-direction motor loads and switching applications where reverse operation is not required. The NC auxiliary contact provides status feedback or interlocking capability in the control circuit.

Key Features

• 3-pole configuration for standard 3-phase or multi-phase load switching
• 6A rating at 440 VAC for light-duty motor and load control
• 24 VDC coil voltage for compatibility with low-voltage DC control circuits
• Normally closed (NC) auxiliary contact for interlocking or status monitoring
• Non-reversible action for single-direction load applications
• Compliant with UL, CSA, IEC 60947, RoHS, VDE 0660, and additional international standards

Compatibility

Designed as an OEM-style IEC contactor replacement for light-duty 3-pole motor control and switching applications requiring a 24 VDC coil and NC auxiliary contact configuration per IEC 60947 standards.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and any applicable local codes. De-energize and lock out the control panel before removing or installing the contactor. Verify coil voltage matches the control circuit supply before energizing. Confirm load current does not exceed the 6A rating at the application voltage.
