Schneider Electric LP1K0601BD Iec Contactor 3P 6A 24VDC

Product Description

The SCHNEIDER ELECTRIC LP1K0601BD is a 3-pole IEC contactor designed for motor control and power switching applications in industrial and commercial electrical systems. It operates on a 24 VDC coil voltage and is rated for 6 amps at 440 VAC. The contactor is non-reversible and includes a normally closed (NC) auxiliary contact configuration. Licensed electricians and industrial maintenance technicians install this device in motor control centers, control panels, and machinery enclosures where reliable switching under IEC standards is required.

The LP1K0601BD is suited for light-duty motor starting and load switching in industrial control panels, HVAC equipment, and process machinery. Its compact footprint makes it a practical choice for space-constrained enclosures in both new installations and retrofit applications. The NC auxiliary contact supports interlocking and status-monitoring circuits commonly found in automated control systems.

Key Features

• 3-pole configuration handles three-phase or multi-phase load switching
• 24 VDC coil voltage compatible with low-voltage DC control circuits
• 6-amp rating at 440 VAC for light-duty motor and load control
• Normally closed (NC) auxiliary contact for interlocking and monitoring circuits
• Non-reversible action for straightforward single-direction motor control
• Compliant with IEC 60947, UL Listed, CSA, RoHS, VDE 0660, BS 5424, and NF C 63-110

Compatibility

Designed as an OEM-style replacement IEC contactor for light-duty motor control and switching applications governed by IEC 60947 standards.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable local codes. De-energize and lock out the control panel before mounting or wiring the contactor. Verify that control circuit voltage matches the 24 VDC coil rating before energizing. Confirm auxiliary contact wiring aligns with the NC configuration before commissioning the circuit.
