Schneider Electric LC2K1210B7 Iec Reversible Contactor

Product Description

The SCHNEIDER ELECTRIC LC2K1210B7 is a 3-pole IEC reversible contactor designed for motor control and power switching applications in industrial and commercial electrical systems. It operates on a 24 volt AC coil at 50/60 Hz and features a normally open (NO) auxiliary contact configuration. The reversible design allows the contactor to control forward and reverse motor rotation within a single assembly. Licensed electricians and industrial maintenance technicians install this component as part of motor starter and drive control panels. It measures 2.3 inches in height, 2.6 inches in width, and 3.7 inches in depth, keeping it compact for panel layouts.

The LC2K1210B7 is suited for reversing motor starter applications in commercial and light industrial environments. It fits within standard IEC-compliant control panels and motor control centers where 24 volt AC control circuits are used. The contactor is appropriate for pump, fan, conveyor, and other three-phase motor loads where direction control is required. Its compact footprint makes it compatible with DIN-rail or panel-mount configurations common in industrial automation and building systems.

Key Features

• 3-pole design with normally open (NO) auxiliary contact configuration
• Reversible operation enables forward and reverse motor control in a single unit
• 24 volt AC coil voltage rated for both 50 Hz and 60 Hz systems
• Compact dimensions of 2.3 x 2.6 x 3.7 inches fit standard control enclosures
• Meets multiple international standards including IEC 60947, UL Listed, CSA, VDE 0660, and RoHS Compliant

Compatibility

Designed as an OEM-style IEC reversible contactor replacement suitable for 3-pole motor control applications using 24 volt AC control circuits in IEC 60947-compliant installations.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC and local electrical codes. De-energize and lock out all power to the control panel before removing or installing the contactor. Verify coil voltage and pole configuration match the existing circuit before making connections. Do not exceed the rated electrical load for the contactor as specified by the system design documentation.
