Schneider Electric LC2K0610B7 Iec Contactor 3P 6A 24V

Product Description

The SCHNEIDER ELECTRIC LC2K0610B7 is a 3-pole IEC contactor designed for reversible motor control and load switching in industrial and commercial electrical systems. It operates on a 24-volt AC coil at 50/60 Hz and carries a 6-amp rating at 440 volts AC. The auxiliary contact is configured as normally open (NO), supporting standard control circuit signaling. At 0.8 pounds, it is a compact unit suited for control panel installation. Licensed electricians and industrial maintenance technicians install this contactor as part of motor starters, reversing drive circuits, and automated switching assemblies.

This contactor is intended for use in industrial control panels, motor control centers, and machine automation systems where reversible three-phase motor operation is required. Its IEC-rated design makes it a standard fit for commercial and light industrial applications across HVAC, conveyor, pump, and compressor circuits. The reversible configuration allows forward and reverse motor direction control through interlocked contactor pairs. It is packaged as a single unit suitable for panel builders, OEM integrators, and field service technicians working to IEC 60947 standards.

Key Features

• 3-pole configuration for three-phase load switching
• Reversible action supports forward and reverse motor control
• 24-volt AC coil rated for both 50 Hz and 60 Hz systems
• Normally open (NO) auxiliary contact for control circuit feedback
• Compliant with IEC 60947, UL Listed, CSA, RoHS, VDE 0660, BS 5424, and NF C 63-110
• Compact form factor at 2.3 x 2.5 x 3.6 inches for dense panel layouts

Compatibility

Designed as an OEM-style replacement or new-installation IEC contactor for 3-pole reversible motor control applications rated to IEC 60947 standards.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the National Electrical Code (NEC) and applicable IEC or local standards. De-energize and lock out the panel before mounting, wiring, or replacing the contactor. When used in a reversing application, ensure mechanical and electrical interlocking is in place between the forward and reverse contactors to prevent phase-to-phase faults. Verify coil voltage supply matches 24 volts AC at the appropriate frequency before energizing.
