Schneider Electric LC2K0601B7 Iec Reversible Contactor 3P 6A 24V

Product Description

The SCHNEIDER ELECTRIC LC2K0601B7 is a 3-pole IEC reversible contactor designed for motor control and power switching applications in industrial and commercial electrical systems. It operates on a 24V AC coil voltage at 50/60 Hz and is rated for 6 amps at 440V AC. The contactor includes a normally closed (NC) auxiliary contact configuration and is built for reversible operation, allowing forward and reverse motor direction control from a single unit. Licensed electricians and industrial maintenance technicians typically specify this contactor for motor starter panels, control cabinets, and automated equipment. Its compact footprint makes it well suited for space-constrained enclosures.

The LC2K0601B7 is applied in light-duty motor control circuits where reversible operation is required. Typical installations include conveyor systems, small pump and fan reversing starters, and other 3-phase motor-driven equipment operating at low control voltages. The 24V AC coil makes it compatible with common low-voltage control transformer outputs found in industrial and commercial control panels. This contactor is intended for installation by qualified electricians working to NEC or applicable IEC wiring standards.

Key Features

• 3-pole configuration for 3-phase motor control circuits
• Reversible action for forward and reverse motor operation
• 24V AC coil voltage at 50/60 Hz for low-voltage control circuits
• 6A rating at 440V AC suitable for light-duty motor loads
• NC auxiliary contact included for interlocking and status signaling
• Certified to multiple standards including UL Listed, CSA, IEC 60947, RoHS Compliant, VDE 0660, BS 5424, and NF C 63-110

Compatibility

Designed as an OEM-style IEC reversible contactor replacement for 3-pole motor control applications requiring a 24V AC coil and NC auxiliary contact in IEC 60947-compliant installations.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC requirements or applicable local codes. De-energize and lockout/tagout the control panel before installing or replacing the contactor. Verify coil voltage supply matches the 24V AC rating before energizing. Ensure auxiliary contact wiring is correct for the intended interlocking scheme before returning the circuit to service.
