Schneider Electric LC2D25B7 Iec Reversible Contactor 25A

Product Description

The SCHNEIDER ELECTRIC LC2D25B7 is a 3-pole IEC reversible contactor rated for 25 amps at 440 volts AC, designed for controlling three-phase motor loads that require forward and reverse operation. The coil operates on 24 volts AC at 50/60 Hz, making it compatible with standard low-voltage control circuits. An integrated auxiliary contact configuration provides both a normally closed (NC) and normally open (NO) auxiliary, supporting interlock and status-feedback wiring in reversing starter assemblies. Licensed electricians and industrial control panel builders install this contactor in motor control centers, panel boards, and standalone starter enclosures.

The LC2D25B7 is suited for reversing motor starter applications in light industrial and commercial settings. Its IEC-rated design fits compact enclosure layouts where space is limited. The reversible action is built into the contactor frame, eliminating the need for separate mechanical interlock hardware in many configurations. Typical applications include conveyor drives, pump reversing systems, and HVAC fan motor controls where directional switching of a three-phase motor load is required.

Key Features

• Reversible 3-pole contactor supports forward and reverse motor control in a single unit
• 25-amp rating at 440 volts AC for three-phase load circuits
• 24-volt AC coil at 50/60 Hz compatible with standard low-voltage control power supplies
• Integrated NC and NO auxiliary contacts for interlock and feedback wiring
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, and RoHS compliance
• Compact IEC form factor suited for space-constrained panel installations

Compatibility

Designed as an OEM-style IEC reversible contactor replacement for 3-pole motor starter applications rated up to 25 amps at 440 volts AC with a 24-volt AC control coil.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC and applicable local electrical codes. De-energize and lockout/tagout all control and load-side power before removing or installing the contactor. Verify coil voltage and pole rating match the existing circuit before wiring. Auxiliary contact wiring for interlock circuits should be confirmed against the panel schematic before energizing the starter assembly.
