Schneider Electric LC2D12G7V Iec Reversible Contactor 3 Pole 12A

Product Description

The SCHNEIDER ELECTRIC LC2D12G7V is a 3-pole IEC reversible contactor rated at 12 amps at 440 Vac, designed for motor reversing and switching applications in industrial and commercial control panels. The coil operates at 120 Vac at 50/60 Hz, making it compatible with standard North American control-circuit voltages. It includes an auxiliary contact configuration of one normally closed (NC) and one normally open (NO), supporting interlocking and feedback circuits. Licensed electricians and industrial control technicians install this device in motor starter assemblies, conveyor systems, pump controls, and similar three-phase load applications where forward and reverse operation is required.

The LC2D12G7V is suited for three-phase motor control installations in light industrial and commercial environments. Its reversible action allows a single contactor assembly to handle bidirectional motor switching without requiring separate forward and reverse units. The built-in NC and NO auxiliary contacts support standard interlocking schemes used in motor control circuits. This contactor is appropriate for panel builders, maintenance electricians, and automation technicians working on replacement or new-build motor control centers.

Key Features

• Reversible contactor action supports forward and reverse motor control in a single unit
• 3-pole configuration rated at 12A at 440 Vac for three-phase load switching
• 120 Vac coil voltage at 50/60 Hz suits standard North American control circuits
• Auxiliary contacts include one NC and one NO for interlocking and status feedback
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, and RoHS Compliant
• Compact footprint suitable for space-constrained control panel installations

Compatibility

Designed as an OEM-style IEC reversible contactor replacement for 3-pole motor control applications requiring a 120 Vac coil and NC/NO auxiliary contact configuration per EN/IEC 60947-4-1.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the control panel before removing or installing the contactor. Verify coil voltage and pole rating match the existing circuit before energizing. Confirm auxiliary contact interlocking wiring is correct before commissioning a reversing motor circuit to prevent simultaneous forward and reverse energization.
