Schneider Electric LC2D12B7 Iec Reversible Contactor 12A

Product Description

The SCHNEIDER ELECTRIC LC2D12B7 is a 3-pole IEC reversible contactor rated at 12 amps at 440 volts AC, designed for motor control and power switching applications in industrial and commercial electrical systems. The contactor operates on a 24-volt AC coil at 50/60 Hz and includes both normally closed (NC) and normally open (NO) auxiliary contact configurations. Its reversible action allows forward and reverse motor direction control within a single device. Licensed electricians and industrial maintenance technicians install this contactor in motor control centers, panel boards, and machine control circuits.

This contactor is suited for three-phase motor starter and reversing starter applications in commercial and light industrial environments. Its compact footprint makes it a practical fit for control enclosures and motor control center (MCC) buckets. The NC/NO auxiliary contacts support interlocking and status feedback wiring common in reversible motor control schemes. It meets a broad range of international standards, making it applicable across domestic and export equipment builds.

Key Features

• Reversible 3-pole design enables forward and reverse motor direction control
• 12A rating at 440V AC for reliable motor switching performance
• 24V AC coil at 50/60 Hz for low-voltage control circuit compatibility
• Integrated NC and NO auxiliary contacts for interlocking and feedback circuits
• Certified to UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, RoHS, and additional international standards
• Compact body measuring 3.5 inches high, 3.7 inches wide, and 3.4 inches deep

Compatibility

Designed as an OEM-style IEC reversible contactor replacement for 3-pole motor control applications requiring a 24V AC coil and NC/NO auxiliary contact configuration in systems conforming to IEC 60947-4-1 standards.

Installation Notes

Installation should be performed by a qualified electrician in accordance with the NEC and any applicable local codes. De-energize and lock out the control panel and all associated circuits before mounting or wiring the contactor. Verify coil voltage matches the control circuit supply before energizing. Auxiliary contact interlocking wiring for reversing starters must be reviewed carefully to prevent simultaneous forward and reverse coil energization.
