Schneider Electric LC2D09BL Iec Contactor 3 Pole 9A 24vdc

Product Description

The SCHNEIDER ELECTRIC LC2D09BL is a 3-pole IEC contactor rated at 9 amps at 440 VAC with a 24 VDC control coil. It is configured for reversible operation, making it suited for motor starter applications that require forward and reverse direction control. The unit includes an auxiliary contact block with one normally closed (NC) and one normally open (NO) contact configuration. Licensed electricians and industrial maintenance technicians install this contactor as part of motor control circuits in panel boards, motor control centers, and standalone enclosures. It meets a broad set of international standards including UL 508, CSA C22.2 No. 14, and EN/IEC 60947-4-1.

The LC2D09BL is designed for industrial and commercial motor control applications where reversing duty is required. Typical installations include conveyor systems, pumps, fans, compressors, and other three-phase motor loads that demand bidirectional operation. The 24 VDC coil voltage makes it compatible with low-voltage control circuits commonly used in programmable logic controller (PLC) output stages and automated machine control panels. It is appropriate for both new installations and replacement service in existing motor control equipment.

Key Features

• Reversible contactor configuration supports forward and reverse motor control in a single device
• 9 amp rating at 440 VAC suits small to mid-range three-phase motor loads
• 24 VDC coil integrates directly with PLC outputs and low-voltage control circuits
• NC and NO auxiliary contacts included for interlocking, status signaling, or pilot device wiring
• Certified to UL 508, UL Listed, CSA C22.2 No. 14, EN/IEC 60947-4-1, EN/IEC 60947-5-1, CCC, GOST, DNV, GL, RINA, LROS, Bureau Veritas, and RoHS Compliant

Compatibility

Designed as an OEM-style IEC contactor replacement for three-phase motor control circuits requiring reversing duty at 9 amps and a 24 VDC control coil voltage.

Installation Notes

Installation must be performed by a licensed electrician in accordance with NEC Article 430 and applicable local codes. De-energize and lock out all power sources before removing or installing the contactor. Verify coil voltage and pole ampacity match the existing circuit before energizing. Proper interlocking between the forward and reverse contactors is required to prevent simultaneous energization.
