Schneider Electric LC2D09B7 Iec Contactor 3 Pole 9A

Product Description

The SCHNEIDER ELECTRIC LC2D09B7 is a 3-pole IEC contactor rated for 9 amps at 440 volts AC with a 24-volt AC coil operating at 50/60 Hz. It is designed for reversible motor control applications and includes both normally closed (NC) and normally open (NO) auxiliary contact configurations. This contactor is installed in motor control centers, industrial panels, and commercial HVAC or pump control circuits. Licensed electricians and industrial controls technicians are the typical installers. Its compact frame — 4.5 inches tall, 3.8 inches wide, and 5.3 inches deep — suits tight enclosure layouts without sacrificing contact accessibility.

The LC2D09B7 is suited for reversible motor starter assemblies where two contactors are interlocked to reverse three-phase motor rotation. Common applications include conveyor systems, pump controls, fan reversals, and HVAC equipment requiring forward and reverse operation. The reversible configuration eliminates the need for additional auxiliary interlocking hardware in many standard reversing starter setups. This contactor meets the demands of both light industrial and commercial building automation environments where IEC-rated devices are specified.

Key Features

• 3-pole reversible contactor rated 9 amps at 440 volts AC
• 24-volt AC coil compatible with 50 Hz and 60 Hz control circuits
• Auxiliary contacts include both NC and NO configurations
• Compact footprint: 4.5 x 3.8 x 5.3 inches for panel space efficiency
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, and RoHS
• Reversible action supports direct use in interlocked reversing starter assemblies

Compatibility

Designed as an OEM-style IEC contactor for use in reversible motor starter and control panel assemblies requiring a 3-pole, 9-amp, 24-volt AC coil device per IEC 60947-4-1 specifications.

Installation Notes

Installation should be performed by a qualified electrician in accordance with NEC and applicable local codes. De-energize and lock out the control panel before mounting or wiring this contactor. Verify coil voltage matches the control circuit supply before energizing. When used in a reversing starter assembly, ensure mechanical and electrical interlocking is correctly configured between the forward and reverse contactors per the manufacturer wiring diagram.
