Schneider Electric LC1K09004F7 Iec Contactor 4 Pole 110V

Product Description

The SCHNEIDER ELECTRIC LC1K09004F7 is a 4-pole, non-reversible IEC contactor designed for switching and controlling electrical loads in industrial and commercial power circuits. Operating on a 110V AC coil at 50/60 Hz, this contactor provides reliable load switching across four independent poles. Its compact form factor measures 3 inches in height, 2.4 inches in width, and 2 inches in depth, making it suitable for installation in confined panel enclosures. Licensed electricians and control panel builders typically specify this device when building motor control circuits, HVAC equipment panels, or multi-phase load switching applications.

This contactor is applied in light industrial, commercial HVAC, and building automation systems where non-reversible 4-pole load switching is required. It is suited for use in motor starters, lighting control panels, and general-purpose switching assemblies that operate on 110V AC control voltage. The 50/60 Hz compatibility allows deployment across both North American and international installations. Panel shops and OEM equipment builders commonly use this contactor as a control component in assembled electrical panels and packaged equipment.

Key Features

• 4-pole, non-reversible configuration for multi-circuit load switching
• 110V AC coil voltage compatible with 50 Hz and 60 Hz power systems
• Compact footprint at 3 inches height, 2.4 inches width, and 2 inches depth
• Meets multiple international standards including IEC 60947, UL Listed, CSA, VDE 0660, and RoHS Compliant
• Lightweight at 0.4 pounds, reducing panel load and simplifying mounting

Compatibility

Designed as an OEM-style replacement or new-install IEC contactor for 4-pole, non-reversible switching applications in control panels and electrical assemblies requiring a 110V AC coil voltage.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the control panel before mounting or wiring the contactor. Verify coil voltage supply matches the 110V AC rating before energizing. Do not use this contactor in reversible motor starter configurations, as it is rated for non-reversible operation only.
