Schneider Electric LC1G500KUEN Contactors, High Power, TeSys Giga, Standard Version, 3 Pole/NO, AC-3 <=440V 500A, 100-250VAC/DC Coil

Product Description

The Schneider Electric LC1G500KUEN is a high power contactor designed for AC-3 applications. This contactor can handle up to five hundred amperes at four hundred forty volts. It features a three pole design with a normally open configuration. The product includes a wide band low consumption electronic coil, suitable for a range of one hundred to two hundred fifty volts AC or DC.

• Compact size for space-efficient installations
• Maximum operating cycles up to six hundred per hour
• IP2x protection rating for enhanced safety

Product Highlights

This contactor offers high reliability and durability with a mechanical lifespan of up to five million cycles. It features Local Contact Wear Diagnosis for continuous monitoring, allowing for quick and easy maintenance without disconnecting power connections.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: LC1G500KUEN

Technical Specifications

• Catalog Number: LC1G500KUEN
• Country of Origin: France
• Rated Current: 500A
• Voltage Rating: 440V AC
• Coil Voltage: 100-250VAC/DC
• Dimensions: 290mm x 140mm x 209mm (H x W x D)
• Protection Rating: IP2x
• Mechanical Durability: 5 million cycles
