Schneider Electric LC1G400KUEN Contactor, High Power, TeSys Giga, Standard Version, 3 Pole/NO, AC-3 <=440V 400A, 100-250VAC/DC Coil

Product Description

Schneider Electric LC1G400KUEN is a high power contactor designed for AC-3 applications up to 400A and 250kW at 440V. It features a wide band electronic coil that accepts 100 to 250 volts AC or DC and includes a highly reliable auxiliary contact block. This contactor operates effectively in demanding conditions, with a maximum rating of 600 cycles per hour and suitable for environments up to sixty degrees Celsius.

• Durable design with five million cycles of mechanical durability
• Local Contact Wear Diagnosis for ongoing monitoring
• IP2x protection in compliance with IEC standards

Product Highlights

The LC1G400KUEN provides reliable operation and maintenance features such as easy access to control connections and the option for direct mounting. The compact design allows for space-saving installations, and the contactor supports a wide operating temperature range from negative twenty-five degrees Celsius to sixty degrees Celsius.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: LC1G400KUEN

Technical Specifications

• Catalog Number: LC1G400KUEN
• Country of Origin: France
• Manufacturer: Schneider Electric
• Operating Temperature Range: -25C to 60C
• Dimensions: 290mm x 140mm x 209mm (H x W x D)
• Cycles per Hour: 600
• Mechanical Durability: 5 million cycles
• Protection Class: IP2x
