Schneider Electric LC1G330EHEA Contactors, High Power, TeSys Giga, AC-3, up to 440V, 330A

Product Description

Schneider Electric LC1G330EHEA is a high power contactor designed for AC-3 applications. It supports voltages up to 440V and handles currents up to 330A. This contactor features a 48-130V AC/DC coil and is suited for motor control and power switching tasks.

• High power capacity: 330A at up to 440V.
• Easy maintenance with access to control connections from the front.
• Durable design with a mechanical life of 5 million cycles.

Product Highlights

The contactor is built for demanding applications with high operating rates. It includes intelligent diagnostics for electrical contacts and is suitable for environments with temperatures ranging from -25C to 60C.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Schneider Electric

Technical Specifications

• Catalog Number: LC1G330EHEA
• Coil Voltage: 48...130V AC, 50/60 Hz; 48...130V DC
• Application: Power switching; motor control
• Mounting: Mounting Plate
• Contact Configuration: 1 NO + 1 NC; 3 NO
• Country of Origin: China
• Special Features: Built-in bidirectional peak limiting
• IP Protection: IP2x Front face protection
