Schneider Electric LC1G185EHEN TeSys Giga High Power Contactor 185A 48-130VAC/DC Coil

Product Description

Schneider Electric LC1G185EHEN is a high power contactor suitable for AC-3 applications up to one hundred eighty-five amperes. This contactor has three poles and features a wide voltage range electronic coil from forty-eight to one hundred thirty volts AC/DC. The design includes a reliable auxiliary contact block, enhancing performance in demanding environments.

• Maximum operating rate of six hundred cycles per hour.
• IP2x protection ensures safety in operation.
• Supports mounting without cable removal, allowing for easier maintenance.

Product Highlights

This contactor is engineered for durability with a mechanical lifespan of up to five million cycles. It features Local Contact Wear Diagnosis, allowing real-time monitoring and alerts. The contactor is temperature rated for environments from negative twenty-five to sixty degrees Celsius, ensuring functionality under varied conditions.

Product Information

Standard Information

• Catalog Number: LC1G185EHEN
• Brand: Schneider Electric

Technical Specifications

• Dimensions: Two hundred fifty-five mm x one hundred eight mm x one hundred seventy-five mm (H x W x D)
• Weight: Three point six kg
• Voltage Rating: Four hundred forty volts AC
• Amperage Rating: One hundred eighty-five amperes
• Coil Voltage: Forty-eight to one hundred thirty volts AC/DC
• Protection Rating: IP2x
• Certification: CE, CB, CCC, cULus, EAC, Marine
