Schneider Electric LC1F630F7 TeSys F Contactor 600 VAC 630 Amp 3-Pole 1NO Panel Mount Full Voltage Non-Reversing IEC Contactor

Product Description

Schneider Electric LC1F630F7 is a TeSys F contactor designed for motor control applications. This unit supports three poles with a current rating of six hundred thirty amps and operates at a maximum voltage of one thousand volts AC. It is suitable for motor applications up to two hundred fifty kilowatts at four hundred volts. The coil operates at a consumption level of one hundred ten volts in a frequency range of forty to four hundred hertz. It features bolt terminals compatible with bars or cables and is designed for high operational rates of up to twelve hundred cycles per hour.

• High reliability and durability
• Easy installation and maintenance
• Multi-standard certified (IEC, UL, CSA, etc.)

Product Highlights

The contaction system provides excellent performance in varying environmental conditions, withstanding temperatures from negative forty to seventy degrees Celsius. Its drawer-mounted coil facilitates convenience during installation and maintenance. It is certified under multiple standards, ensuring compliance with global electrical safety norms.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Schneider Electric

Technical Specifications

• Catalog Number: LC1F630F7
• Voltage Rating: 1000 Volt
• Weight: 41.01 lb
• Dimensions: 255 mm (Length) x 309 mm (Width) x 304 mm (Height)
• Warranty: 18 months
• Country of Origin: Czech Republic
• Coil Voltage: 110V AC at 40-400 Hz
• Operating Cycles: 1200 cycles/h
