Schneider Electric LC1DT60AG7 Iec Contactor 4 Pole 60A 120V

Product Description

The SCHNEIDER ELECTRIC LC1DT60AG7 is a 4-pole IEC contactor rated for 60 amperes at 440 volts AC, designed for non-reversible motor control and load switching in industrial and commercial electrical systems. Operating on a 120-volt AC coil at 50/60 Hz, this contactor includes both normally closed (NC) and normally open (NO) auxiliary contacts for control circuit integration. Licensed electricians and industrial maintenance technicians install this device as part of motor starter assemblies, HVAC control panels, and multi-phase load control applications. It conforms to a wide range of international standards, making it suitable for projects requiring UL Listing, CSA, or IEC compliance.

The LC1DT60AG7 is used in three-phase and four-pole switching applications across residential, commercial, and light industrial environments. Typical installations include motor control centers, packaged HVAC equipment, pump control panels, and load-shedding circuits where non-reversible operation is specified. The included NC and NO auxiliary contacts allow for interlock wiring, pilot light circuits, or control relay logic without requiring an add-on auxiliary block.

Key Features

• 4-pole non-reversible contactor rated at 60A at 440 volts AC
• 120-volt AC coil operating at 50 Hz and 60 Hz for broad compatibility
• Integrated NC and NO auxiliary contact configuration
• Meets EN/IEC 60947-4-1, EN/IEC 60947-5-1, UL 508, CSA C22.2 No. 14, and multiple international certifications
• Compact footprint: 3 inches tall, 5.4 inches wide, 6 inches deep (nominal)
• Single-unit packaging with no minimum order multiplier requirement

Compatibility

Designed as an OEM-style IEC contactor for use in 4-pole, non-reversible motor control and switching applications where a 120-volt AC control coil and NC/NO auxiliary contacts are required.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC requirements and applicable local codes. De-energize and lock out the panel or motor control center before removing or installing the contactor. Verify coil voltage and pole rating match the existing circuit before wiring. Auxiliary contact terminals should be wired to control circuits only and must not carry load current.
