Schneider Electric LC1D32M7 Iec Contactor 3 Pole 220V

Product Description

The SCHNEIDER ELECTRIC LC1D32M7 is a 3-pole, non-reversible IEC contactor designed for motor control and load switching applications in industrial and commercial electrical systems. It operates on a 220-volt AC coil at 50/60 Hz and includes one normally closed (NC) and one normally open (NO) auxiliary contact configuration. Licensed electricians and industrial maintenance technicians install this contactor in motor control centers, panel boards, and machinery control circuits. The LC1D32M7 carries UL Listed and CSA certifications, making it suitable for installations governed by NEC and Canadian electrical standards.

This contactor is used in three-phase motor control applications across light industrial, commercial HVAC, and process equipment installations. Its non-reversible configuration suits direct-on-line motor starters, lighting control panels, and resistance heating circuits where a single direction of motor rotation is required. The integrated NC/NO auxiliary contacts allow for interlocking, status indication, or control circuit feedback without requiring an add-on auxiliary contact block. Both 50 Hz and 60 Hz coil compatibility makes this unit appropriate for domestic and international equipment installations.

Key Features

• 3-pole configuration for standard three-phase load switching
• 220-volt AC coil rated for both 50 Hz and 60 Hz power systems
• Non-reversible action for direct-on-line motor starter applications
• Integrated NC and NO auxiliary contacts for interlocking or status feedback
• UL Listed, CSA, CCC, DNV, GOST, RoHS Compliant, and EN/IEC 60947-4-1 certified
• Compact footprint at 3.3 inches height, 1.8 inches width, and 3.6 inches depth

Compatibility

Designed as an OEM-style IEC contactor replacement for 3-pole, non-reversible motor control applications requiring a 220-volt AC coil at 50/60 Hz with NC/NO auxiliary contact configuration.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC Article 430 for motor circuit protection and control. De-energize and lockout/tagout the panel or motor control center before removing or installing the contactor. Verify coil voltage at the control circuit matches the 220-volt AC rating before energizing. Inspect auxiliary contact wiring connections for proper termination before returning the circuit to service.
