Schneider Electric LC1D326G7 Iec Contactor 3 Pole 120V

Product Description

The SCHNEIDER ELECTRIC LC1D326G7 is a 3-pole IEC contactor designed for motor control and power switching applications in industrial and commercial electrical systems. It operates on a 120-volt AC coil at 50/60 Hz and is configured as non-reversible with an auxiliary contact block providing one normally closed (NC) and one normally open (NO) contact. Licensed electricians and industrial control technicians install this contactor in motor control centers, panel boards, and machine control enclosures where reliable switching and IEC-standard compliance are required.

This contactor is suited for use in commercial and industrial settings where IEC 60947-series equipment is specified. Typical applications include motor starters, pump controls, HVAC equipment, compressor circuits, and other inductive load switching. The 120-volt coil voltage makes it compatible with common North American control circuit voltages, and its non-reversible configuration is appropriate for single-direction motor loads and general power switching tasks.

Key Features

• 3-pole configuration handles three-phase or multi-phase load circuits
• 120-volt AC coil at 50/60 Hz suits standard North American control circuits
• Non-reversible design for single-direction switching applications
• Auxiliary contacts include one NC and one NO for control circuit feedback or interlocking
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, and EN/IEC 60947-5-1
• RoHS compliant construction

Compatibility

Designed as an OEM-style IEC contactor for use in industrial motor control and power switching panels where 3-pole, 120-volt coil contactors conforming to IEC 60947-series standards are specified.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and any applicable local electrical codes. De-energize and lockout/tagout the control panel and all associated circuits before removing or installing the contactor. Verify that the control circuit voltage matches the coil rating of 120 volts AC before energizing. Confirm auxiliary contact wiring aligns with the control circuit logic before returning the system to service.
