Schneider Electric LC1D25JD IEC Contactor 25A 15HP at 480VAC

Product Description

Schneider Electric LC1D25JD is a non-reversing IEC contactor rated for 25 amperes. This product is suitable for motor control in industrial applications. It can manage resistive loads effectively and integrates seamlessly into various control systems. The contactor is designed for three-phase applications, supporting up to fifteen horsepower at four hundred eighty volts alternating current.

• Rated for 7.5HP at 200-240VAC
• Includes a built-in 12V DC coil
• Compatible with DIN rail and panel mounting

Product Highlights

Ideal for creating motor starters, this contactor features a standard configuration with one normally open and one normally closed auxiliary contact. It is compact, measures three point three five inches tall, one point seven seven inches wide, and three point six two inches deep, weighing zero point eighty-two pounds.

Product Information

Standard Information

• Brand: Schneider Electric
• MPN: LC1D25JD

Technical Specifications

• Operating Cycles: 25...400 Hz
• Coil Voltage: 12 V DC
• Contact Configuration: 1 NO + 1 NC; 3 NO
• Mounting: Rail Plate
• Special Features: Built-in bidirectional peak limiting diode suppressor
• Warranty Description: Contractual Warranty: 18 months
• Country of Origin: France
• GTIN: 03389110356632
