Schneider Electric LC1D186G7 Iec Contactor 3 Pole 120V

Product Description

The SCHNEIDER ELECTRIC LC1D186G7 is a 3-pole IEC contactor designed for motor control and power switching applications in industrial and commercial electrical systems. It operates on a 120-volt AC coil at 50/60 Hz and includes an auxiliary contact configuration of one normally closed (NC) and one normally open (NO) contact. The non-reversible action makes it suited for single-direction motor loads or general load switching. Licensed electricians and industrial maintenance technicians install this contactor in motor control centers, panel boards, and machine control enclosures.

This contactor is intended for use in non-reversing motor starter applications and load control circuits in commercial and light industrial environments. It fits into standard IEC-style control panel layouts and is compatible with DIN rail or panel mounting configurations. The included NC and NO auxiliary contacts support interlock wiring, pilot light circuits, and status feedback in control logic. No specific model compatibility data was provided by the manufacturer for this listing.

Key Features

• 3-pole configuration for three-phase or multi-pole load switching
• 120-volt AC coil rated for both 50 Hz and 60 Hz power systems
• Non-reversible action for single-direction motor or load control
• Auxiliary contact block includes one NC and one NO contact for control circuit integration
• Meets multiple international standards including UL 508, CSA C22.2 No. 14, and EN/IEC 60947-4-1
• RoHS compliant construction

Compatibility

Designed as an OEM-style IEC contactor replacement suitable for non-reversing motor starter and load switching applications in standard IEC control panel assemblies.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and any applicable local codes. De-energize and lock out the control panel before removing or installing this contactor. Verify coil voltage matches the control circuit supply before energizing. Auxiliary contact wiring should be completed and verified before returning the system to service.
