Schneider Electric LC1D096G7 Iec Contactor 3 Pole 120V

Product Description

The SCHNEIDER ELECTRIC LC1D096G7 is a 3-pole IEC contactor designed for motor control and load-switching applications in industrial and commercial electrical systems. It operates on a 120-volt AC coil at 50/60 Hz and features a non-reversible action with an auxiliary contact configuration of one normally closed (NC) and one normally open (NO). Licensed electricians and industrial maintenance technicians install this contactor in motor starters, control panels, and distribution equipment where reliable switching and broad certification coverage are required.

This contactor is suited for use in commercial and industrial environments where IEC-rated switching devices are specified. Its compact footprint — 4.7 inches tall, 2.1 inches wide, and 3.7 inches deep — allows installation in space-constrained control enclosures. The 120-volt coil voltage makes it compatible with standard North American control circuit wiring. It is appropriate for motor starter assemblies, HVAC equipment control panels, pump control circuits, and similar low-voltage control applications.

Key Features

• 3-pole non-reversible switching action for straightforward motor control circuits
• 120-volt AC coil rated for both 50 Hz and 60 Hz systems
• Auxiliary contact configuration includes one NC and one NO contact
• Compact body measuring 4.7 x 2.1 x 3.7 inches fits standard control enclosures
• Carries UL 508, CSA C22.2 No. 14, EN/IEC 60947-4-1, and RoHS compliance certifications
• Recognized by Bureau Veritas, DNV, GL, GOST, and additional international certification bodies

Compatibility

Designed as an IEC-style contactor for use in motor control and industrial control panel applications requiring a 3-pole, 120-volt AC coil device with NC/NO auxiliary contacts.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the NEC and any applicable local codes. De-energize and lock out the control panel before mounting or wiring the contactor. Verify that the control circuit voltage matches the 120-volt AC coil rating before applying power. Follow the manufacturer wiring diagram for auxiliary contact terminations to ensure proper circuit function.
