Schneider Electric LADN10 Auxiliary Contact Block with Screw Terminal 10A 690 VAC

Product Description

LADN10 is a Schneider Electric auxiliary contact block designed for TeSys D and TeSys F contactors. This front-mounted block provides one normally open contact, with a current rating of ten amps and voltage rating of six hundred ninety volts AC. It features a clip-on mounting method for easy installation and high reliability.

• Compatible with TeSys D and TeSys F contactors
• Electrical durability rated for several million cycles under standard operating conditions
• Multi-standard certified including IEC, UL, and CSA

Product Highlights

This auxiliary contact is suitable for various applications in control and automation, offering instantaneous operational capability.

Product Information

Standard Information

• Catalog Number: LADN10
• Brand: Schneider Electric

Technical Specifications

• Voltage: 690 Volts AC
• Current Rating: 10 Amps
• Dimensions: Width 0.51 inches, Depth 1.38 inches, Height 1.89 inches
• Operating Temperature: -5 to 60 degrees Celsius
• Storage Temperature: -60 to 80 degrees Celsius
• Weight: 0.04 lb
• Standards: UL Listed, CSA Certified
• Mounting Type: Front mount, screw clamp terminals
