Schneider Electric LAD8N20 TeSys Deca Auxiliary Contact Block 2 NO Side Mount Screw Clamp Terminals for LC1D09 to LC1D150 Contactors

Product Description

Schneider Electric LAD8N20 is an auxiliary contact block designed for use with TeSys D contactors. This block features two normally open (NO) contacts and mounts on the side of contactors rated from nine amps to one hundred fifty amps. It integrates seamlessly into control systems, allowing for efficient motor starter configurations across various applications. The compact design of the auxiliary contact block simplifies setup while ensuring compatibility with international standards. It also supports quick installation with screw clamp terminals, enhancing its ease of use in the field.

• Two NO contacts for control circuits
• Side mount design for space efficiency
• Compatible with LC1D09 to LC1D150 contactors

Product Highlights

This auxiliary contact block meets multiple international certifications, ensuring reliability and performance in any setting.

Product Information

Standard Information

• Catalog Number: LAD8N20
• Manufacturer: Schneider Electric

Technical Specifications

• Warranty Description: Contractual Warranty: eighteen months
• Country of Origin: Indonesia
• Contact Configuration: Two NO
• Coil Voltage: Six hundred ninety V AC, twenty-five to four hundred Hz
• Maximum Load Current: Ten A
• Operating Temperature: Negative five to sixty degrees Celsius
• Rated Insulation Voltage: Six hundred ninety V IEC 60947-5-1
• Insulation Resistance: Greater than ten MOhm
