Schneider Electric LAD4VU Square D 110 to 250 VAC Varistor Type Suppressor Module

Product Description

The Schneider Electric LAD4VU is a suppressor module designed for use with LC1D09 to LC1D38 contactors and CAD control relays. This unit operates at a voltage range of 110 to 250 volts AC and limits transient voltage to a maximum of two times the operating voltage. It features clip-on side mounting, ensuring that the overall size of the contactor remains unchanged. The module is compliant with Green Premium standards (RoHS and REACh).

• Compatible with LC1D09-D38 and LC1DT20-DT40 contactors.
• Limits transient voltage, maximizing reliability.
• Easy installation with clip-on mounting.

Product Highlights

This suppressor module is essential for protecting contactors from high voltage surges, ensuring long-term durability and operational efficiency.

Product Information

Standard Information

• Catalog Number: LAD4VU
• Manufacturer: Schneider Electric

Technical Specifications

• Coil Voltage: 110 to 250 VAC
• Item Type: Suppressor module; Varistor
• Weight: 0.03 lb
• Country of Origin: France
• Warranty Length: 18 months
• Operating Temperature: -25 to 55 degrees C
• Mounting Type: Clip
• Standards: CSA, UL certifications
