Schneider Electric GV7AC022 Circuit Breaker Connector

Product Description

The SCHNEIDER ELECTRIC GV7AC022 is a clip-on connector designed for use with circuit breakers in the TeSys product family. It provides a secure, tool-free electrical connection point that attaches directly to compatible GV7R-series circuit breakers. The connector simplifies wiring during panel assembly or field service by eliminating the need for direct terminal screw access. Electrical and instrumentation professionals working on motor protection and control circuits will find this part a straightforward replacement or supplemental connection component. Weighing 0.09 pounds, it is compact and easy to handle during installation.

This connector is used in industrial and commercial control panel applications where TeSys-series motor circuit breakers are installed. It is suited for new panel builds as well as retrofit and service work on existing motor protection assemblies. The GV7AC022 attaches to GV7R circuit breakers and supports clean, organized wiring in tight enclosures where direct terminal access is limited.

Key Features

• Clip-on mounting for quick attachment to compatible circuit breakers without additional hardware
• Designed specifically for GV7R-series TeSys motor circuit breakers
• Compact footprint: 2.3 inches long, 2 inches wide, 1 inch tall
• Lightweight construction at 0.09 pounds
• Sold individually, allowing single-unit replacement or incremental panel builds

Compatibility

Compatible with GV7R and TeSys series circuit breakers as specified by the manufacturer.

Installation Notes

Installation should be performed by a qualified electrician or instrumentation technician. De-energize and lock out the panel before attaching or removing any connector. Verify that the breaker is fully seated and in the off position before clipping the connector in place. Work should comply with applicable NEC requirements for industrial control wiring.
