Schneider Electric GB2CB14 Square D 1-Pole 8 Amp 300 VAC Thermal Magnetic Circuit Protector

Product Description

The Schneider Electric GB2CB14 is a thermal magnetic circuit protector designed for protecting industrial equipment control circuits. This device operates at eight amps and supports a voltage of two hundred fifty volts. The circuit protector features thermal-magnetic technology, with a magnetic tripping level set at one hundred eight amps and a breaking capacity of one point five kiloamperes at two hundred forty volts. It is also suitable for DC loads up to eight amps at forty-eight volts.

• Compact design at fifteen millimeters wide
• Mounts easily on thirty-five millimeter DIN rails
• Toggle lever control with guaranteed eight thousand cycles start-stop

Product Highlights

This product offers reliable protection for a variety of control circuits and meets multi-standard certifications including IEC, UL, and CSA.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Brand: Schneider Electric

Technical Specifications

• Catalog Number: GB2CB14
• Amperage: 8 Amp
• Voltage: 250 Volt
• Number of Poles: 1 Pole
• Height: 74 mm
• Width: 15 mm
• Depth: 67 mm
• Country of Origin: France
