Schneider Electric GB2CB07 Square D 1-Pole 2 Amp 300 VAC Thermal Magnetic Circuit Protector

Product Description

Schneider Electric GB2CB07 is a thermal magnetic circuit protector designed to safeguard industrial control circuits. Rated at two amps and operating at a maximum voltage of 250 VAC, it excels in providing reliable protection. This device features a compact design measuring fifteen millimeters in width, suitable for mounting on thirty-five millimeter DIN rails. It ensures thermal-magnetic protection with a magnetic trip level set at twenty-six amps, providing a breaking capacity of fifteen kiloamperes at two hundred forty volts.

This circuit breaker can also be utilized for direct current applications up to two amps at forty-eight volts DC-13, with a breaking capacity of one point five kiloamperes at twenty-four volts. The toggle lever control allows for ease of operation and guarantees a start-stop action for up to eight thousand cycles. This product is sold in packs of six units and meets multiple standards including IEC, UL, and CSA, making it a Green Premium product under RoHS and REACh regulations.

• Compact dimension of fifteen millimeters wide
• Magnetic tripping level at twenty-six amps
• Multi-standard certified for various applications

Product Highlights

The Schneider Electric GB2CB07 circuit protector provides thermal-magnetic protection for various electrical applications.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Catalog Number: GB2CB07
• Voltage: 250 Volt
• Amperage: 2 Amp
• Number of Poles: 1 Pole
• Width: 15 mm
• Height: 74 mm
• Depth: 67 mm
• Country of Origin: France
• Warranty: 18 months
