Schneider Electric VS2325 Steam 3/4NPT 5.0Cv 2Way

Product Description

Schneider Electric (Erie) VS2325 is a two-way solenoid valve suitable for steam applications. The valve includes a three-quarter inch NPT connection and a flow capacity of five. It is made from cast iron with a brass stem and seat, designed for durability and reliability in demanding environments.

• Suitable for pressures up to one hundred fifty psi.
• Operates at temperatures as high as three hundred sixty-six degrees Fahrenheit.
• Compatible with high-temperature actuators.

Product Highlights

This valve is ideal for controlling fluid flow in heating and cooling systems. Its rugged construction ensures long-term performance.

Product Information

Standard Information

• Brand: Schneider Electric (Erie)
• MPN: VS2325
• Connection Type: Threaded
• Body Pattern: 2-Way

Technical Specifications

• Flow Capacity (Cv): 5
• Max Pressure: 150 psi
• Max Temperature: 366°F
• Weight: 0.97 lbs
• Dimensions: 3.8 inches Length x 3.45 inches Width x 2.5 inches Height
