Schneider Electric CAD32G7 Square D Control Relay 120 VAC 10 Amp 5-Pole

Product Description

Schneider Electric CAD32G7 is a control relay designed for electromagnetic loads. It has five contacts with a configuration of three normally open (3NO) and two normally closed (2NC). This relay operates on a control circuit of 120 volt alternating current at fifty or sixty hertz. The connection is made via screw clamp terminals, ensuring secure attachment in various applications. The device is suitable for high operating rates, reaching up to one hundred eighty cycles per minute, and can function under ambient temperatures ranging from negative forty to sixty degrees Celsius.

• 5 Contacts Configuration (3NO + 2NC)
• Rated Voltage of up to 690 Volt
• Compatible with various control systems

Product Highlights

This control relay offers high reliability and durability, making it suitable for industrial and automation environments. Its compact design allows for easy installation on standard DIN rails or mounting with screws. It also meets multiple industry standards including IEC, UL, and CSA.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Catalog Number: CAD32G7
• Weight: 1.28 lb
• Dimensions: 45 mm Width x 77 mm Height x 84 mm Depth
• Voltage: 690 Volt
• Amperage: 10 Amp
• Operating Cycles: 180 cyc/min
• Country of Origin: Indonesia
• Warranty: 18 months
