Schneider Electric CA2KN22G7 Control Relay 120 VAC 10 Amp 4-Pole 2NO 2NC

Product Description

Schneider Electric CA2KN22G7 is a control relay designed for various automation tasks. It operates at 120 VAC with a rating of 10 Amp and features four contacts, which include two normally open (2NO) and two normally closed (2NC). This relay is suitable for controlling electromagnetic loads with compliance to AC-15 and DC-13 standards. The control circuit is compatible with 50/60Hz inputs and connects via screw clamp terminals. The relay supports high operational rates of up to 180 cycles per minute and operates effectively within ambient temperatures ranging from negative twenty-five to fifty degrees Celsius.

• Four contacts: 2NO + 2NC
• Compact design for DIN rail or screw mounting
• Multi standard certifications including IEC, UL, CSA, and more

Product Highlights

This control relay is built for reliability and longevity, featuring a compact size of 45 millimeters in width. It is recognized as a Green Premium product under RoHS and REACh guidelines.

Product Information

Standard Information

• Brand: Schneider Electric
• Manufacturer: Square-D / Schneider

Technical Specifications

• Catalog Number: CA2KN22G7
• Voltage: 690 Volt
• Amperage: 10 Amp AT <= 50 ?C
• Width: 45 mm
• Height: 58 mm
• Depth: 57 mm
• Weight: 0.40 lb
• Contact Configuration: 2 NO + 2 NC
