Schneider Electric ATV320D15M3C SQD ATV320 Variable Speed Drive 15kW 200 to 240V AC

Product Description

The Schneider Electric ATV320D15M3C is a variable speed drive suitable for various industrial applications. Designed for Original Equipment Manufacturers (OEMs), it operates at a rated power of up to fifteen kilowatts and supports voltage levels from two hundred to two hundred forty volts AC. Its compact design allows for vertical stacking within machine frames.

• Robust construction for operation in harsh environments.
• Supported ambient temperatures up to sixty degrees Celsius without additional cooling.
• Includes multiple safety functions for compliance with international standards.

Product Highlights

This model offers enhanced torque and speed control at low speeds, making it suitable for applications such as packaging, material handling, and mechanical actuation.

Product Information

Standard Information

• Catalog Number: ATV320D15M3C
• Brand: Schneider Electric

Technical Specifications

• Rated Power: 15 kW
• Voltage Rating: 200 to 240 volts AC
• Weight: 6.9 kg
• Dimensions: 180 mm (W) x 330 mm (H) x 198 mm (D)
• Phases: 3 Phase
• Operating Temperature: -25 to 70 degrees Celsius
• Certifications: IEC, UL, TUV, KC, and others
