Schneider Electric ATV212HU55N4 Square D Variable Speed Drive 7.5 Hp 480V 3 Phase

Product Description

The Schneider Electric ATV212HU55N4 is a three-phase variable speed drive designed to operate motors at a rated power of up to 5.5 kilowatts or 7.5 horsepower, and at voltages between 380 to 480 volts AC. It features an IP21 protection index and includes a built-in EMC filter for effective electromagnetic compatibility. This drive optimizes energy consumption, reducing it by up to seventy percent compared to conventional systems.

With technology that minimizes cable temperature rise, the ATV212 provides immediate and disturbance-free operation, eliminating the need for additional components like line or DC chokes to manage harmonic distortion. Weighing approximately 3.35 kilograms, it has dimensions of one hundred forty-two millimeters in width, one hundred eighty-four millimeters in height, and one hundred fifty millimeters in depth. This drive is particularly suitable for fluid management applications in HVAC systems including heating, ventilation, air conditioning, and pumping.

Compliance with IEC/EN standards ensures safety and reliability, while certifications such as CE, UL, and CSA affirm its global market readiness. The drive also includes optional motor chokes, extending cable lengths between the drive and motor, effectively reducing disturbances at the motor terminals. It can be mounted vertically with four fixing holes and interacts seamlessly with various building management systems using integrated communication protocols such as Modbus and BACnet.

• Rated Power: 5.5kW (7.5 hp)
• Input Voltage: 380-480V AC
• Weight: 3.35 kg; Dimensions: 142mm (W) x 184mm (H) x 150mm (D)

Product Highlights

This variable speed drive is engineered for efficiency and reliability in managing HVAC and fluid systems.

Product Information

Standard Information

• Brand: Schneider Electric
• Catalog Number: ATV212HU55N4

Technical Specifications

• Output Voltage: Equal to input voltage
• Phase: 3
• Country of Origin: Indonesia
• Weight: 7.39 lb (3.35 kg)
• Warranty: 18 months
