Schneider Electric ATV212HU22M3X variable speed drive 2.2kW 3hp 240V 3ph

Product Description

The Schneider Electric ATV212HU22M3X is a variable speed drive designed for 3-phase asynchronous motors. This unit operates efficiently at a power range of up to 2.2 kW or 3 hp, operating on a voltage range of 200 to 240 volts AC. The drive has an IP21 protection rating, making it suitable for various environments.

• Reduces energy consumption by up to 70% compared to traditional systems.
• Lightweight design of 1.8 kg with compact dimensions of one hundred seven millimeters wide, one hundred forty-three millimeters high, and one hundred fifty millimeters deep.
• Compatible with building management systems using integrated communication protocols like Modbus and BACnet.

Product Highlights

This drive improves efficiency in HVAC applications and conforms to IEC and UL standards. It offers options for motor chokes to minimize disturbance at motor terminals.

Product Information

Standard Information

• Brand: Schneider Electric
• Country of Origin: Indonesia

Technical Specifications

• Catalog Number: ATV212HU22M3X
• Rated Power: 2.2 kW (3 hp)
• Rated Voltage: 200-240V AC
• Protection Index: IP21
• Weight: 1.8 kg (3.97 lb)
• Dimensions: 107 mm (W) x 143 mm (H) x 150 mm (D)
• Compliance: CE, UL, CSA, C-Tick, NOM
• Warranty Length: 18 months
