Schneider Electric ABR1S302B Interface Relay - Electromechanical, 1 C/O, 12 A conforming to IEC 60947-1, 125 V DC

Product Description

The Schneider Electric ABR1S302B is an electromechanical output interface module. This interface relay features one changeover contact and operates at a rating of twelve amps conforming to IEC standards. It is designed for din rail mounting, making it suitable for a variety of automation and control applications.

• Rated for twelve amps at DC voltage
• Designed for use on din rails
• Suitable for various industrial applications

Product Highlights

This relay offers a green mechanical indicator showing contact position, and it features a green LED light to indicate control signal status.

Product Information

Standard Information

• Manufacturer: Schneider Electric
• Country of Origin: France

Technical Specifications

• Catalog Number: ABR1S302B
• Connection: Screw clamp terminal
• Contact Configuration: 1 C/O
• Contact Rating: 62 mA DC
• Mounting: Din Rail
• Operating Cycles: 6 Hz at no-load, 0.5 Hz at IE
• Operating Temperature: -20 to 60 degrees Celsius, unrestricted operation
• Special Features: Green mechanical indicator for contacts, green LED control signal state
