Schneider Electric 9013FHG2J43 Air-Compressor Pressure Switch 80 Psi Set Off 20 Psi Fixed Differential 1/4 Npsf Internal

Product Description

The Schneider Electric 9013FHG2J43 Air-Compressor Pressure Switch is designed for controlling electrically driven air compressors. The switch activates at a set threshold and is configured to turn off at 80 psi. It features a 1/4 NPSF internal fluid connection, making it suitable for motors with 1.5 hp power or less.

• 80 psi set off point
• 20 psi fixed differential
• 1/4 NPSF internal connection

Product Highlights

This pressure switch is ideal for air compressors with lower horsepower motors. It has a non-adjustable differential of 20 psi and a cut-out range of 40-100 psi. The diaphragm-actuated switch is equipped with screw terminal electrical connections and two 2-pole NC contacts that open on rising pressure. The enclosure meets NEMA Type 1 and IP20 standards, ensuring safety and reliability.

Product Information

Standard Information

• Brand: Schneider Electric (Square D)
• MPN: 9013FHG2J43

Technical Specifications

• Pressure Range: 20 to 100 psi
• Differential: 20 psi
• HP @ 1 Phase - 120V: 1.5 hp
• HP @ 1 Phase - 240V: 2 hp
• HP @ 3 Phase - 240V: 3 hp
• HP @ 3 Phase - 480V: 1 hp
• Temp. Range: -22 to 257 degrees F
• Electrical Connection: Screw-Clamp Terminals
• Enclosure Rating: NEMA Type 1, IP20
• Country of Origin: Mexico
• Certifications: UL Listed, CSA Certified
