Schneider Electric 9001SKT1G31 Press-to-test Indicating Light

Product Description

The SCHNEIDER ELECTRIC 9001SKT1G31 is a green lens press-to-test indicating light designed for industrial control panel and operator interface applications. It operates at 110 VAC or 120 VAC at 50/60 Hz via transformer, providing a reliable visual status indication on machinery, switchgear panels, and control enclosures. The round lens design and screw clamp connector simplify installation and wiring. Built to resist corrosion, dust, and oil, this pilot light is suited for demanding industrial environments where panel components are exposed to contaminants and moisture. Licensed electricians and controls technicians are the primary installers.

This indicating light is used in industrial and commercial control panel applications requiring a transformer-powered pilot light with press-to-test lamp verification. The press-to-test function allows technicians to confirm lamp operation without interrupting the control circuit, making it practical for routine panel inspections. The green lens is a standard color code for run, power-on, or normal-status indication across most machine control and process automation installations.

Key Features

• Green round lens for standard run or power-on status indication
• Press-to-test function allows lamp verification without circuit interruption
• Operates at 110 VAC or 120 VAC at 50/60 Hz via transformer
• Screw clamp connector for secure, tool-assisted wiring termination
• Rated corrosion resistant, dust resistant, and oil resistant for harsh environments
• Meets NEMA 1, 2, 3, 3R, 4, 4X, 6, 12, and 13 enclosure ratings

Compatibility

Designed as an OEM-style replacement pilot light for industrial control panels requiring a transformer-powered, green lens press-to-test indicating light with a screw clamp connector.

Installation Notes

Installation should be performed by a licensed electrician or qualified controls technician in accordance with the NEC and applicable local codes. De-energize and lock out the control panel before removing or installing the indicating light. Verify transformer output voltage matches the rated operating voltage of the light before energizing. Screw clamp terminals require a small flat-blade screwdriver for proper termination.
